Argon ONE V5 Case for Raspberry Pi 5 - Premium Casted Aluminum Enclosure
Transform your Raspberry Pi 5 into a professional powerhouse with the Argon ONE V5 Case. Built from premium cast aluminum, this sleek black enclosure provides exceptional passive and active cooling, extensive port expansion, built-in audio DAC, and compatibility with expansion modules. Perfect for desktop computers, home servers, Home Assistant setups, and high-performance projects.
Premium Casted Aluminum Design with Advanced Cooling
The entire cast aluminum body acts as a massive heatsink, providing exceptional passive cooling. Combined with an intelligent 30mm PWM fan, your Raspberry Pi 5 stays cool even under heavy workloads - perfect for 24/7 server operation.
Key Features
Premium Construction
- Cast Aluminum Body - Solid, durable construction with matte black finish
- Passive Heatsinking - Entire case acts as efficient heatsink
- Active Cooling - Built-in 30mm PWM fan with intelligent control
- Professional Appearance - Sleek design perfect for desktop use
Enhanced Connectivity
- Dual Full-Size HDMI Ports - 4K output on both displays
- Front USB 2.0 Ports - Two additional USB ports for easy access
- Built-in Audio DAC - 3.5mm mic input and headphone output (HS100B chip)
- All Pi 5 Ports - Full access to USB 3.0, Ethernet, USB-C
Expandability
- HAT Compatible - Standard Raspberry Pi HAT support
- Internal USB Port - For ZigBee modules (Home Assistant)
- Expansion Ready - Compatible with Argon expansion modules
- Optional M.2 NVMe - Upgrade path available (separate purchase)
Smart Features
- Power Button - Convenient front-mounted power control
- SD Card Access - Easy access with removable cover
- Passive + Active Cooling - Best thermal performance
- PWM Fan Control - Quiet operation, ramps up when needed
Technical Specifications
| Case Design |
| Material |
Cast Aluminum (body), Plastic (base) |
| Finish |
Matte Black |
| Compatibility |
Raspberry Pi 5 ONLY |
| Cooling System |
| Passive Cooling |
Entire aluminum body acts as heatsink |
| Active Cooling |
30mm PWM fan with intelligent control |
| Thermal Pads |
Included for optimal heat transfer |
| Ports & Connectivity |
| Front Ports |
2x USB 2.0, 3.5mm audio (mic + headphone), Power button, SD card access |
| Rear Ports |
2x Full-size HDMI (4K), 2x USB 3.0, Ethernet, USB-C power |
| Audio |
Built-in DAC (HS100B chip) with mic input and headphone output |
| Internal |
USB port for ZigBee/IoT modules, GPIO header access |
| Expandability |
| HAT Support |
Standard Raspberry Pi HAT compatible |
| M.2 NVMe |
Upgrade path with expansion board (sold separately) |
| Optional Add-ons |
OLED display, ZigBee module, NVMe expansion |
| Package Contents |
| Included |
Aluminum case, 30mm PWM fan, Thermal pads, Mounting hardware, HDMI-USB2-Audio daughterboard, SD card cover, Assembly instructions |
Argon ONE V5 Variants
| Variant |
Features |
Best For |
| V5 Case Only (This) |
Base case, cooling, audio, ports - No NVMe |
Desktop use, general projects, upgradable later |
| V5 M.2 Case |
Base features + Single M.2 NVMe slot |
Fast boot drive, single SSD storage |
| V5 Dual M.2 Case |
Base features + Dual M.2 NVMe slots |
NAS, RAID, maximum storage expansion |
Upgrade Path Available
Start with the base case and add M.2 NVMe expansion later if needed. The case is designed to accept Argon's M.2 expansion boards (single or dual), giving you flexibility to upgrade as your needs grow.
What Makes Argon ONE V5 Special?
1. Exceptional Cooling
The cast aluminum construction provides massive passive cooling. The 30mm PWM fan remains nearly silent during normal use but automatically ramps up when needed. This combination keeps your Pi 5 cool even during sustained workloads like 24/7 server operation.
2. Professional Port Layout
Front-mounted USB ports and audio jack provide easy access for daily use. All rear ports are neatly organized with full-size HDMI connectors - no more micro HDMI adapters!
3. Built-in Audio DAC
The HS100B DAC chip provides high-quality audio with both microphone input and headphone output. Perfect for video calls, media playback, and voice assistant projects.
4. Expansion Ecosystem
Argon has created a complete ecosystem around the V5 case:
- M.2 NVMe Expansions - Single or dual SSD slots
- OLED Display - Real-time system stats on top of case
- ZigBee Module - Perfect for Home Assistant
- UPS Battery - Uninterruptible power supply
Perfect For Many Applications
Desktop Computer
Dual 4K displays, front USB ports, audio in/out - perfect desktop setup
Home Assistant
Internal USB for ZigBee, always-on operation, excellent cooling
Media Center
Dual 4K HDMI, audio DAC, silent operation, professional look
Home Server
24/7 operation, excellent cooling, upgrade to NVMe storage
Development
HAT compatible, GPIO access, stable cooling for compiling
NAS
Add M.2 expansion for fast networked storage
What's Included
- 1x Argon ONE V5 Aluminum Case - Cast aluminum body with plastic base
- 1x 30mm PWM Fan - Pre-installed with intelligent control
- 1x HDMI-USB2-Audio Daughterboard - Port breakout and audio DAC
- Thermal Pads - For optimal heat transfer to case
- Mounting Hardware - Screws and standoffs
- SD Card Cover - Optional cover for SD slot
- Assembly Instructions - Detailed setup guide
What You Need (Sold Separately)
Required - NOT Included
- Raspberry Pi 5 - REQUIRED (4GB, 8GB, or 16GB)
- 27W USB-C Power Supply - Official Raspberry Pi PSU recommended
- MicroSD Card - Or boot from USB/NVMe (with expansion)
- HDMI Cable(s) - Full-size HDMI connectors
Important Information
Raspberry Pi 5 ONLY
This case ONLY fits Raspberry Pi 5. It will NOT work with Raspberry Pi 4B, 3B+, or any other Raspberry Pi model. The case is specifically designed for the Pi 5's port layout and dimensions.
Software Setup Required
To enable the PWM fan control, front USB ports, and audio DAC, you need to install the Argon ONE software:
- Download and run the Argon ONE installation script
- Add configuration line to /boot/firmware/config.txt
- Reboot to activate all features
- Installation guide provided with case
M.2 NVMe Expansion Available
This base case can be upgraded with Argon's M.2 NVMe expansion boards (sold separately). Choose single or dual M.2 slots depending on your storage needs. SSDs not included with expansion boards.
Assembly Overview
Installation Steps
- Apply thermal pads to Raspberry Pi 5 chips
- Connect Pi 5 to HDMI-USB2-Audio daughterboard
- Route fan cable through case guide posts
- Place assembly in aluminum case
- Secure with provided screws
- Attach plastic base with screws
- Install software for fan control and ports
Assembly time: Approximately 15-20 minutes
Thermal Performance
Independent reviews show the Argon ONE V5 provides excellent thermal performance:
- Idle Temperatures - Significantly cooler than stock Pi 5
- Load Temperatures - Stays well below throttling point even under stress tests
- Silent Operation - Fan barely audible during normal use
- 24/7 Capable - Designed for continuous server operation
Optional Expansion Modules
Available Separately:
- M.2 NVMe Single - Add one M.2 2280 SSD (PCIe Gen 2.0)
- M.2 NVMe Dual - Add two M.2 2280 SSDs (PCIe Gen 2.0, 500MB/s per lane)
- Argon Industria OLED Display - Shows CPU temp, usage, IP address, time
- Argon Industria ZigBee Module - For Home Assistant and smart home
- UPS Battery Backup - Sits under case for power protection
Frequently Asked Questions
Q: Does this fit Raspberry Pi 4?
A: No. This case ONLY fits Raspberry Pi 5. The port layout and dimensions are completely different.
Q: Can I add M.2 NVMe storage later?
A: Yes! Purchase the M.2 expansion board separately (single or dual). The case is designed to accept these expansions.
Q: Is the fan loud?
A: No. The 30mm PWM fan is very quiet during normal operation and only ramps up when needed. Most users report it being whisper-quiet.
Q: Does it include NVMe SSD slots?
A: This base version does NOT include M.2 slots. You need to purchase the M.2 expansion board separately, or buy the M.2 version of the case.
Q: Can I use HATs with this case?
A: Yes! The case is designed to accommodate standard Raspberry Pi HATs with internal clearance.
Q: Does it come with Raspberry Pi 5?
A: No. Raspberry Pi 5 is sold separately.
Q: What's the difference between this and the M.2 versions?
A: This base case has no M.2 slots. The M.2 version includes one NVMe slot. The Dual M.2 version includes two NVMe slots. All share the same cooling and port features.
